Stenter Automatic Padder Dosing Machine

Introduction

The Stenter Automatic Padder Dosing Machine provides precise online control of softener and finishing solution concentration during stenter processing. It continuously monitors the solution and automatically adds raw material when the concentration falls below the preset value. This keeps the padding solution consistent from the beginning to the end of production, helping achieve uniform fabric feel and stable quality. With 0.1% measurement and control precision, PLC operation, automatic cleaning, and a compact SUS304 design, the system helps textile mills improve productivity while reducing manual work, chemical waste, and process variation.

Technical Parameter

Measurement and control precision : 0.1%
Liquid circulation : Cylinder diaphragm pump, electric diaphragm pump
Operation interface : Touch screen
Power : 0.37kW
Air pressure : 6bar
Material : SUS304

Instructions

• Before starting the machine, prepare the material tank with a solution of appropriate concentration and set the initial values;
• After normal startup, the soft oil in the solution will be absorbed by the cloth and become diluted;
• Real-time concentration can be monitored at any time through an intelligent online solution concentration detector;
• When the monitored concentration is lower than the user-set initial value, the PLC sends a signal to start the feeding pump, injecting the raw material into the circulation pipeline to keep the solution concentration close to the user-set value, ensuring a consistent feel for the fabric from top to bottom;
• This feeding method is convenient, intuitive, and easy to operate, making it suitable for users who require a high level of dexterity.

Why Choose the Stenter Automatic Padder Dosing Machine?

Choose the Stenter Automatic Padder Dosing Machine for consistent finishing quality, precise chemical control, and reduced manual operation. Its intelligent online concentration detector continuously monitors the padding solution. When the concentration drops below the preset value, the PLC automatically activates the feeding pump. This keeps the softener concentration stable and provides a more consistent fabric hand feel throughout production.

With measurement and control precision of 0.1%, the system minimizes concentration variation. It also reduces the uncertainty associated with manual dosing. The automatic cleaning function simplifies maintenance, while the compact structure saves valuable floor space. The touch-screen interface provides simple and intuitive operation.

By automating chemical replenishment, the machine can reduce labor requirements, chemical waste, and energy loss. It also helps minimize production inconsistencies and improve overall process efficiency.
